Stop by to see Micro Lambda Wireless at our partner’s booth, M-RF Company, Ltd., at the Microwave Workshop and Exhibition (MWE) in Yokohama, Japan, from November 27th to 29th,, Stand# C-04!
Yttrium iron garnet (YIG) delivers the undisputed lowest phase noise and tuning speed of any RF/microwave synthesizer or filter technology. Learn how to put it at your fingertips with the best optimized YIG synthesizer or YIG filter test box made just for you. This is the kind of ATE equipment you've been dreaming of. So stop by our partners ES-France at the European Microwave Show, Stand ...
Micro Lambda Wireless, Inc. announces the production release of new 120 series of bandreject filters. Standard frequency models are available covering 6 GHz to 18 GHz, 8 GHz to 20 GHz and 6 GHz to 20 GHz.
Whether you are looking for extremely wide bandwidths or very deep notch depths, these filters will fit the bill. These filters will meet the most stringent requirements.
Combine to add the ...
80 MHz bandwidths at -40 dBc now available over 6.0 to 20.0 GHz tuning range YIG-Based Notch Filters for EW and ECM
Micro Lambda Wireless, Inc. has developed a new Yittrium Iron Garnet based filter that provides superior notch depths over the 6 to 18 GHz and 6 to 20 GHz frequency range. This new filter provides a tunable notch of 80 MHz min. at 40 dBc down. The 3 dB bandwidth is 250 MHz max. with ...
We're pleased to announce that we've increased the offerings for our high-performance, low phase noise benchtop frequency synthesizers. In sync with our evolving catalog of YIG synthesizer components, our custom-tuned benchtop YIG synthesizer line now offers RF and microwave designers working at frequencies up to 20 GHz the chance to upgrade their test benches with the best technology ...
This fast-switching frequency synthesizer keeps the spurious and phase-noise levels low across a total frequency tuning range as wide as 50 MHz to 21 GHz.
Microwave signal sources must deliver on many different levels. Depending on the application, they may need to switch frequencies quickly, often in fine frequency steps, and always with low phase noise. Achieving this combination of high performance ...
Yttrium Iron Garnet (YIG) is a synthetic crystal that offers very high Q characteristics. (Learn more about Q factor in this wiki post: https://en.wikipedia.org/wiki/Q_factor ). This high Q provides the lowest phase noise performance in oscillators, and the most optimal multi-octave frequency tuning in both oscillators and filters.
YIG crystals are “grown”, like silicon crystals. The ...
1. YIG RF Bandpass Filters:
In an RF bandpass filter, the coupling loops are aligned at a 90° angle to prevent direct RF coupling. One end of each loop is grounded. This prevents the filtered signal from being reflected.
The RF input signal of the coupling loop modulates the magnetic field around the YIG sphere, this modulation is coupled to the magnetic field resonating around the YIG sphere, ...
MLMS-Series Frequency Synthesizers 250 MHz to 16 GHz:
Micro Lambda Wireless, Inc. announces the production release of a new smaller and lower cost frequency synthesizer designed to fit into a single slot PXI chassis. Standard frequency models are available covering 250 MHz to 6 GHz, 2 to 8 GHz, 6 to 13 GHz and 8 to 20 GHz. Special customer defined frequency ranges within the entire frequency range ...
If you're looking for a high-quality YIG-Tuned Oscillator, look no further. Our YIG-Tuned Oscillator designs cover frequency ranges from 500 MHz to 44 GHz. Both narrow band or wideband configurations are available in the standard product offerings. Permanent Magnet designs covering the 2 GHz to 22 GHz fundamental ranges, through 44 GHz using frequency doublers and Electromagnetic designs covering ...
We're pleased to announce the production release of our MLUN-Series YIG-Tuned bandreject filters with 50 dB notch depths at 500 MHz and 60 dB notch depths starting at 2 GHz. Standard models cover the 500 MHz to 2 GHz, 2 to 6 GHz, 6 to 18 GHz and 2 to 18 GHz.
The standard model operates over the 0 to +65 C temperature range, but Military versions covering -40 to +85C are available ...
Using small conductive “loops” a YIG filter is coupled to and from a YIG spheres’ resonant magnetic field. The closer the loop, the wider the bandwidth. Bandwidth can also be expanded by increasing the number of YIG resonators and carefully “tuning” the RF coupling loops. In this brief, RF engineers will learn the three basic methods in which this coupling is applied: ...
